Why do you need the WolfKatz Engineering Fuel Rail for your 3S-GTE
powered MR2 Turbo (USDM 1991-1995)? Simply because the factory rail's
hole is too SMALL! See for yourself in the pictures below.
The factory rail has a tiny 3 mm hole causing a pressure drop at the
last injector in line. Just look at the difference! The WolfKatz Fuel
Rail uses an 11/32" hole (roughly 8.7mm) that eliminates the pressure
drops found when larger side feed injectors are used (like the side feed
550's found on the Gen IV Supra Turbo). Wolfkatz testing found a 17%
reduction in flow to the last injector using the stock rail, or about 3
psi total drop from inlet to outlet.
In the past, many people performed drastic modifications to the factory
rail (the so called "dual feed" setup) to overcome this problem while
losing the ability to run the factory cold start injector. When faced
with performing this modification to their personal car, Wolfkatz became
extremely uncomfortable with the task. This process involves drilling
out the factory rail which potentially weakens this die cast aluminum
part. Instead of spending the nearly $300 required for fittings, tubing
and special tools to perform this tedious modification, they designed
the WolfKatz Fuel Rail! Now you can simply order the WolfKatz Fuel Rail
and have a much simpler system that uses the stock supply and return
lines as well as the stock fuel pressure regulator (every kit also
includes an AN-6 male fitting pictured above in case you want to run an
aftermarket FPR). The factory FPR has been proven to operate up to 400
whp without problems.
The WolfKatz Rail is compatible with factory 440 cc/min injectors, Supra
Gen IV 550's , MR2 T Gen III 540's, SARD 800's, and the Blitz 850's.
How is the WolfKatz Fuel Rail made? Each rail is NC Machined from a
billet piece of 6061 T6 Aluminum. This process allows the rails to be
built to the demanding tolerances required to create a perfect seal
around each side feed injector. An early version of the rail has been
running successfully in the WolfKatz Factory car for over 3 years with
absolutely no problems! Each part is machined, de-burred and then
finished by TIG welding the required plug in the end of the rail.
Included with the rail is a six page instruction set to be sure your
installation goes smoothly. All hardware and fittings needed for a the
rail installation are included.
Not sure what rail is right for you? Read the MR2 Fuel Rail FAQ Here!
